RadMini Error 30 Troubleshooting Guide

In the unlikely event you see an error 30 message on your RadMini, perform a connector check to ensure all connectors are secure and in good condition.

Follow the steps below to the connectors on your bike to resolve the issue. This guide uses a 2019 RadMini, but the steps will be similar for other RadMini models.

Caution.png If you are not confident in your ability to successfully and safely perform all steps, we recommend having the work performed or checked by a local, certified, and reputable bike mechanic.

Tools Needed:

  • Flat side cutters
  • Phillips head screwdriver (for 2016-2018 models)
  • A camera
  • Zip ties

Connector Check Steps:

Perform the following steps on one connector at a time until the error message is resolved.

  1. Get the bike ready for maintenance. Turn off the bike, remove the battery, and press and hold MODE on the LCD display remote to discharge remaining power.

  2. Check the battery and battery mounting tray terminal contacts. If the contacts are wet, dirty, or damaged, take a photo and contact Rad Power Bikes Product Support. If everything is in good condition, reinstall the battery and turn on the bike to check if the issue is resolved. If the bike will not turn on (or if the issue continues), ensure the bike is turned off, remove the battery, and discharge remaining power.
  3. Check the connection between the battery and the controller. The battery connector is the large connector located near the bottom bracket. The connector is flat on one side and is black inside with two large prongs. Follow the steps below to check the connector.

  4. Locate and unplug the connector. Follow the cable from the part to the connector. Snip zip ties for easier access, then pull each side of the connector directly apart without twisting.

    For 2016-2018 models: Use a Phillips head screwdriver to remove the cover plate on the box beneath the battery to access the connectors inside.

  5. Inspect the inside and reconnect. If the inside of the connector is wet, dirty, or damaged, take a photo and contact Rad Power Bikes Product Support. If it looks normal, line up the internal notch and pins (and external indicators) and press directly together without twisting.
  6. Check if the issue is resolved. Reinstall the battery and turn on the bike. If the issue continues, turn off the bike, remove the battery, and discharge remaining power.
  7. Repeat steps 4 through 6 on each connector listed below until the error is resolved. Once resolved, replace zip ties and trim to be flush and smooth. On 2016-2018 models, reinstall the cover plate on the box beneath the battery. Test the bike fully and ride Rad!

Click the headings below to view the location of each connector.

Display Connector
Location: Handlebar area

Color: Silver metal connector; black inside

To unplug: Untwist the metal portion of the connector, then pull directly apart without twisting.

To reconnect: Align the internal notch and pins on the connector ends, and press directly together, without twisting. Then, twist the metal portions until the connector is secure.



Wiring Harness Connector
Location: Near downtube (2019 and newer models) or in the connector box near the bottom bracket (2016-2018 models only)

Color: Black inside


2016-2018 RadMini:

Motor Connector
Location: Near the chainstay, on the right side of the bike

Color: Black inside


Taillight Connector (Only on a 2019 or newer RadMini)
Location: Back of the bike

Color: Blue inside


Second Taillight Connector (Only on a RadMini with a Rear Rack)
Location: on the rear rack

Color: Blue inside

This connector only exists on bikes made in and after 2019 that also have a rear rack installed. Trace the cable from the first taillight connector to the connector plugged into the controller.

Left Brake Connector
Location: Handlebar - left side

Color: Red inside

Trace the cable from the left brake lever to the connector at the front of the bike.



Right Brake Connector
Location: Handlebar - right side

Color: Red inside

Trace the cable from the left brake lever to the connector at the front of the bike.



Throttle Connector
Location: Handlebar area

Color: Yellow inside

Trace the cable from the throttle to the connector at the front of the bike.



Headlight Connector
Location: Front of the bike

Color: Red inside

Trace the cable from the headlight to the connector.


PAS Sensor Connector
Location: Near the bottom bracket

Color: Yellow inside
